G7868 X6 server

Product Overview The G7868 X6 server is compatible with the new HGX 8-GPU module or the standard OAM2.0 module. The modular design significantly enhances the cooling efficiency and maintainability of the entire machine, allowing the powerful performance of the GPU to be fully utilized. The main control unit supports up to 2 CPUs, and in combination with the 8-channel 5600MT/s DDR5 Memory technology, it provides a bandwidth increase of up to 50% for users. With the support of 15 PCIe5.0 slots and up to 29 hard drive slots, it meets the requirements of various computing architecture solutions and further improves the system's computing performance. It can be applied to various large computing scenarios such as large-scale training, high-performance computing (HPC), and large data centers.
Function Highlights 1. Compatible with multiple computing modules
Release super strong computing performance
It can be compatible with 8-GPU modules or standard OAM 1.5-2.0 modules, fully meeting the requirements of high computing power scenarios;
2. Flexible topology design
Adapt to different application scenarios
The GPU topology can be flexibly switched to meet the needs of various computing power scenarios; The PCIe card module can adjust resource allocation according to business needs, helping to fully release computing power performance;
3. Modular design
Comprehensively enhance maintainability
The modular system design enables the main control unit, computing unit, cooling unit and PCIe card unit to support separate maintenance, achieving easy operation and maintenance; Supports liquid cooling modules to meet the cooling requirements of multiple scenarios;
Application Scenarios 1. Large-scale module application
Module training
Learning reasoning
2. High-performance computing Data analysis
Scientific research
3. Data processing
Speech recognition Image processing
4. Data Center
Virtualization
Private Cloud
External Dimensions (H×W×D)
 352mm (height) × 447mm (width) × 882mm (depth)
Form Factor 8U case
GPU Module 8-GPU module (compatible with SXM module and universal OAM 1.5-2.0 module)
Processor Max 2 CPUs, 64 cores per CPU,
Maximum power: 350W
Memory Supports up to 32 DDR5 Memory slots, with a speed of up to 5600 MT/s, supports RDIMM, and has a capacity of up to 8TB;
Supports CXL 1.1 and HBM technology
Storage Controller Integrated 6Gb/s SATA controller; optional support for 12Gb/s SAS HBA and 12Gb/s SAS RAID controller
Hard Disk Expansion System SAS/SATA/NVMe hard drive configuration:
Supports up to 29 2.5-inch hard drives, among which NVMe hard drives support a maximum of 12, and supports 2 2280/22110 SATA or 1 2280/22110 NVMe M.2 SSD.
PCIe Expansion Up to 15 PCIe 5.0 expansion slots are supported.
Up to 14 X16 PCIe 5.0 standard slots are supported (6 from the CPU and 8 from the Switch).
Up to 6 X16 PCIe 5.0 FH standard slots are supported.
1 onboard OCP3.0 slot is supported.
management software Integrated BMC management chip AST2600, supporting functions such as IPMI2.0, Redfish, SOL, KVM, and virtual media.
network Supports 1 OCP3.0 network card, and optional 1/10/25/50/100/200/400GE PCIe standard network cards.
security Supports intrusion detection for the chassis; supports PFR3.0 and SGX2.0 security technologies; supports TCM/TPM security modules
fan The fan supports 15 high-performance fans, with N+1 hot-swappable redundant fans.
power supply Support 6 3500W 54V platinum power supplies (will support 4200W/5200W in the future), and can optionally expand with 2 2000W/2400W/2700W/3200W 12V platinum power supplies. Optional titanium power supply * is also available. Supports N+N redundancy/N+1 redundancy.
operating temperature 0℃ to 35℃ (The working temperature is subject to different configurations and may vary.)
