E530-4T12X

E530-4T12X

Product Overview E530 series three-layer Ethernet switch (hereinafter referred to as "E530") is a high-performance switch built on Ethernet switching chip CTC7132, supporting multiple port types. E530 is equipped with CentecOS system software, supports mainstream protocol standards and applications, and enables convenient and rapid deployment and management.
Description

12 x 10GE SFP+ ports
Fixed single AC power supply design
Left and right direction fixed fans
Front and rear / Rear and front direction fixed fans
Weight 2.80KG
Management interface One RJ45 type serial port, one RJ45 out-of-band management port, and one standard USB port
Interface 4*1GE Base-T port
12*10GE SFP+ port
Switching Capacity 248 Gbps
Packet Forward Speed 184.51 Mpps
Operating Temperature
 0 to 45 ºC
Storage Temperature -40 to 70 ºC
Storage Humidity 0 to 95% (non-condensing)
Packet delay(ns) 660ns
CPU SOC(双核, ARM A53)
Memory 2GB
Flash 8GB(eMMC)
Package cache 9MB
Dual power input NO(Single power input)
Power hot-plug NO(fixed power supply）
MTBF(hours) 131400
MTBF(years) 15
